Wire Drawing

Wire diameter :  1.0-6.0mm,or as your requirements

Application :  Hard drawn wire is the suitable material of iron nails,cloth hanger ,wire mesh,craftwork and so on

Features :  High quality material, good hardness,high tensile strength.

Material :  Q195 wire rod 6.5mm

Black annealling wire and all other wire mesh are manufactured by wire rod. Dechengli buy this material from a big steel factory in Shanxi China. The type of wire rod is Q195, element composition is as follows: C≤0.07; S≤0.023; Si≤0.09; Mn≤0.32; P≤0.025.Because This type of wire rod has less Impurities, Q195 is fit for drawing. The diameter is 6.5mm. Generally, Daily output of D.C.L. is 300 tons.

Produce process :

  1. drawing :  there are two kinds of drawing machine: powder drawing and water drawing. powder drawing is fit for junior drawing(6.5mm~4.0mm). One powder drawing machine has 4 tanks and 4 molds. One tank is matched with a mold. Each of them is offered energy by a electromotor. 0.9 mm(max)can be “eat” when the wire cross a mold. There is no loss of weight during drawing.
  2. oil spraying : we will doing surface disposal with oil spraying to against the rusted
Category:
Description

BWG

mm

BWG

mm

4#

6.045

12#

2.769

5#

5.588

13#

2.413

6#

5.156

14#

2.108

7#

4.572

15#

1.829

8#

4.111

16#

1.651

9#

3.759

17#

1.473

10#

3.404

18#

1.245

11#

3.048

19#

1.067
